Y2 Series IEC standard low noise Three-Phase Induction Motor 6pole 0.18-250Kw F-class
3 Phase Induction Motor
PRODUCT DESCRIPTIONS
The Y2 series three-phase motor adopts the latest technology and design and conforms to the IEC standard. The stator core and the rotor core are made of silicon steel plate, entire copper coil, high-quality material structure, F-class insulation, high torque, safe and reliable operation, beautiful appearance, excellent performance, convenient maintenance, low-temperature rise, low noise, strong overload capability, etc. advantage.
1. The standard working condition of the motor is - 20 ° C to + 40 ° C, 1000 meters above sea level.
2. Grounding device or temporary grounding device to avoid electric shock
2. Do not move with power. You must turn off the power first
3. Troubleshooting must be powered off
APPLICATIONS
The electric motor is suitable for all kinds of machinery, such as pumps, transportation machinery, fans, mixers, food machinery, engineering machinery, packaging machinery, compressors, forging machinery, etc.
THREE-PHASE INDUCTION MOTOR FEATURES
1. Consistent performance
2. Low maintenance
3. Suitable for mounting in any position
4. Easy to operate
OPERATING LIMITS
1. Priming voltage: 380V or any voltage between 220-760V
2. Sea level: not exceed 1000m. If over, the power will be down
3. Environment temperature: -15℃ ≦ 0 ≦ 40℃
4. Protection: IP44 / IP54 / IP55
5. Insulation Class: B / F / H
Details
  | THE COPPER COILS The coil adopts the new national standard copper wire to ensure the high efficiency, stability, and safe operation of the motor |
| BEARING Ensure motor service life, high strength carbon steel quality, with good dust-proof effect |  |
 | HIGH PRECISION ROTOR New national standard rotor,multi-precision processing, through rigorous dynamic and static balance test, to ensure smooth operation and low noise |
PERFORMANCE CHART
| Ist/In | Power | (A) | Power | Eff. (%) | Speed | Tstart/Tn | Ist/In | Tmax/Tn |
| (kw) | Factor | (r/min) |
| Synchronous Speed 1000 r/min (6 Poles) |
| Y2-711-6 | 0.18 | 0.74 | 0.66 | 56 | 900 | 2.2 | 4 | 2.2 |
| Y2-712-6 | 0.25 | 0.94 | 0.68 | 59 | 900 | 2 | 4 | 2.2 |
| Y2-801-6 | 0.37 | 1.3 | 0.7 | 62 | 900 | 2 | 5 | 2.2 |
| Y2-802-6 | 0.55 | 1.8 | 0.72 | 65 | 900 | 2 | 5 | 2.2 |
| Y2-90S-6 | 0.75 | 2.3 | 0.72 | 69 | 910 | 2 | 5.5 | 2.2 |
| Y2-90L-6 | 1.1 | 3.2 | 0.73 | 72 | 910 | 2 | 5.5 | 2.2 |
| Y2-100L-6 | 1.5 | 3.9 | 0.75 | 76 | 940 | 2 | 5.5 | 2.2 |
| Y2-112M-6 | 2.2 | 5.6 | 0.76 | 79 | 940 | 2 | 6.5 | 2.2 |
| Y2-132S-6 | 3 | 7.4 | 0.76 | 81 | 960 | 2 | 6.5 | 2.2 |
| Y2-132M1-6 | 4 | 9.7 | 0.76 | 82 | 960 | 2 | 6.5 | 2.2 |
| Y2-132M2-6 | 5.5 | 12.9 | 0.77 | 84 | 960 | 2 | 6.5 | 2 |
| Y2-160M-6 | 7.5 | 16.5 | 0.77 | 86 | 970 | 2 | 6.5 | 2 |
| Y2-160L-6 | 11 | 24.1 | 0.78 | 87.5 | 970 | 2 | 6.5 | 2 |
| Y2-180L-6 | 15 | 31.5 | 0.81 | 89 | 970 | 2 | 7 | 2 |
| Y2-200L1-6 | 18.5 | 38.5 | 0.81 | 90 | 970 | 2 | 7 | 2 |
| Y2-200L2-6 | 22 | 44.6 | 0.83 | 90 | 970 | 2 | 7 | 2 |
| Y2-225M-6 | 30 | 59.3 | 0.84 | 91.5 | 980 | 2 | 7 | 2 |
| Y2-250M-6 | 37 | 71 | 0.86 | 92 | 965 | 2 | 7 | 2 |
| Y2-280S-6 | 45 | 86 | 0.86 | 92.5 | 980 | 2 | 7 | 2 |
| Y2-280M-6 | 55 | 105 | 0.86 | 92.8 | 980 | 2 | 7 | 2 |
| Y2-315S-6 | 75 | 141 | 0.86 | 93.5 | 990 | 2 | 7 | 2 |
| Y2-315M-6 | 90 | 169 | 0.86 | 93.8 | 990 | 2 | 7 | 2 |
| Y2-315L1-6 | 110 | 206 | 0.86 | 94 | 990 | 2 | 6.7 | 2 |
| Y2-315L2-6 | 132 | 244 | 0.87 | 94.2 | 990 | 2 | 6.7 | 2 |
| Y2-355M1-6 | 160 | 292 | 0.88 | 94.5 | 990 | 1.9 | 6.7 | 2 |
| Y2-355M2-6 | 200 | 365 | 0.88 | 94.7 | 990 | 1.9 | 6.7 | 2 |
| Y2-355L-6 | 250 | 455 | 0.88 | 94.9 | 990 | 1.9 | 6.7 | 2 |
3 Phase Induction Motor GUARANTEE
Guarantee for one year from shipped on board date. During the guarantee period, our company will provide free easy-damaged spare parts for problems caused by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect artificial operation. In addition, after expiration, our company provides cost spare parts for maintenance.
OUR SERVICE
1. Directly factory sale.
2. Quick response to 2-8hours, response rates over 92%.
3. 24 hours phone call is available. Feel free to contact us.
4. We provide one-stop services for all goods produced by ourselves, from designing printing to processing. Customers can provide the design according to your request and sample making. Also, we can advise how to make the products according to customers' target prices.
FAQ
1. Q: What's the MOQ?
A: We accept one piece.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.
4. Q: What's the warranty period?
A: 1 year.
5. Q: What are the terms of payment?
A: T/T. 30% deposit and 70% against the BL copy or 100% LC at sight.
